200 Watts amplifier diagram:
This is a 200-watt amplifier diagram. This circuit can produce 200 watts using 35-0-35 voltage and 6 amperes. it’s a mono-circuit board. here used 2 transistors. 2sc2922 and 2sa1216 sanken transistors.
The transistor 2SC2922:
The material of the transistor is Si
The polarity is NPN
The maximum Collector Power Dissipation is 200W.
The maximum Collector-Base Voltage is 180V.
The maximum Collector Current max is 17A.
The max operating Junction Temperature is 150 °C.
The transition Frequency is 25 MHz.
The Current Transfer Ratio (hFE), MIN is 33.
The transistor 2SA1216:
The material of the transistor is Si
The polarity is PNP
The maximum Collector Power Dissipation is 200W.
The maximum Collector-Base Voltage is 180V.
The maximum Collector Current max is 17A.
The max operating Junction Temperature is 150 °C.
The transition Frequency is 25 MHz.
The Current Transfer Ratio (hFE), MIN is 33.
The circuit diagram is here
This circuit doesn’t have speaker protection. here need a speaker protection circuit. here is the link to get the speaker protection circuit. Diagram is here
This is the Speaker protection circuit diagram. It can protect our Speaker from the burn. if the amplifier has any problem then this circuit can save our soundbox. Normally when the transistor makes a short circuit the voltage comes out from the speaker output line then this circuit protects that voltage. This circuit should not allow any direct voltage to be sent to the speaker. This circuit is very important for protecting the speaker.
