Electronics Help Care Amplifier circuit diagram Bridge mode dual power amplifier:
This is the bridge mode dual power amplifier. Here we can use TDA2030 or TDA2050. This circuit diagram can make a maximum of 35 watts. Here needs a dual voltage. positive, negative, and ground voltage. minimum 10-0-10 voltage to 18-0-18 voltage can use. TDA2030 runs with a maximum 15-0-15 voltage, and TDA2050 runs with a maximum 22-0-22 voltage. but my claim is maximum 18-0-18 voltage for tda2050 and 15-0-15 for the tda2030.
A good voltage can make a good output of watts.
Details about 2SA1943
2sa1943 Polarity is PNP. The maximum collector power dissipation is 150 Watts. The maximum collector-base Voltage is 250 volts. Max Collector-Emitter Voltage is 250V. The Max Emitter-Base Voltage is 5V. The Maximum Collector Current is 17 amperes.
Details about 2SC5200
2sc5200 Polarity is NPN. The maximum collector power dissipation is 150 Watts. The maximum collector-base Voltage is 250 volts. Max Collector-Emitter Voltage is 250V. The Max Emitter-Base Voltage is 5V. The Maximum Collector Current is 17 amperes.
How to make an amplifier circuit:
How to make an amplifier circuit? This is a mini audio amplifier circuit diagram. It can make 30 watts in bridge mode using 15 volts. This diagram needs a single voltage, positive and negative. It’s a mono diagram. To make a stereo, a dual board is needed. Here, use the TDA2003 IC. The dual IC needs to be in bridge mode. The IC needs a headsink. And the voltage must be good to make the best watts. We can use 8 volts to 18 volts. and up to 3 amperes.
We can get many amplifier circuit diagrams. This circuit can be used in a 2.1 sound box. We can make a subwoofer amplifier using this diagram. To make a subwoofer, we need a low-pass filter circuit. To get the lowpass filter circuit, please visit here: LOWPASS FILTER. We need this low-pass filter to make a bass amplifier for 2.1 audio. This low-pass filter makes the sound only bass. It’s also a pre-amplifier. We can use this circuit in any amplifier to make a subwoofer amplifier.
We have another post for you. like Stk 4101 repairing the amplifier,
Build a Transformer or construct the transformer. Home Theater Circuit Diagram 5.1
Thanks a lot for being with us. If you want another post, please visit our website.
We have another post for you. like repairing amplifiers. If you like electronics, please visit our other post. electronicshelpcare.com
Our Facebook page is Electronicshelpcare
We can also use this circuit as a car amplifier. This circuit runs with a 12-volt battery. The Ic and heatsink need a separator.
