Power amplifier circuit diagram:
This is the Power amplifier circuit diagram using transistors. This circuit can make RMS 100 watts. Here can use 25-0-25 voltage to 50-0-50 voltage. It’s a mono audio circuit. We can use here 2SC5200 and 2SA1943, and other NPN and PNP transistors. like C5198 and A1941. or like 2SC2922 and 2SA1216.
Power amplifier circuit diagram.
Details about C5198
C5198 Polarity is NPN. The maximum collector power dissipation is 100 watts. The maximum collector-base Voltage is 140 volts. Max Collector-Emitter Voltage is 140V. The Max Emitter-Base Voltage is 5V. The Maximum Collector Current is 10 amperes.
Details about A1941
2sa1941 Polarity is PNP. Max Collector Power Dissipation is 100 Watts. The maximum collector-base Voltage is 140 volts. Max Collector-Emitter Voltage is 140V. The Max Emitter-Base Voltage is 5V. The Maximum Collector Current is 10 amperes.
Details about 2SC5200
2sc5200 Polarity is NPN. The maximum collector power dissipation is 150 Watts. The maximum collector-base Voltage is 250 volts. Max Collector-Emitter Voltage is 250V. The Max Emitter-Base Voltage is 5V. The Maximum Collector Current is 17 amperes.
Details about 2SA1943
2sa1943 Polarity is PNP. Max Collector Power Dissipation is 150 Watts. The maximum collector-base Voltage is 250 volts. Max Collector-Emitter Voltage is 250V. The Max Emitter-Base Voltage is 5V. The Maximum Collector Current is 17 amperes.
This is the Speaker protection circuit diagram. It can protect our Speaker from the burn. If the amplifier has any problems, this circuit can save our soundbox. Normally, when the transistor makes a short circuit, the voltage comes out from the speaker output line, and this circuit protects that voltage. This circuit should not allow direct voltage to be sent to the speaker. This circuit is essential for protecting the speaker.
We have another post for you. like Amplifier circuit 200 watts
Transistor circuit for an amplifier
Build a Transformer or construct the transformer. Home Theater Circuit Diagram 5.1
Thanks a lot for being with us. If you want another post, please visit our website.
