Electronics Help Care Amplifier circuit diagram This is an audio equalizer circuit diagram, 7-band. It’s an audio graphic equalizer board. It’s a mono board. It has 7 audio graphic controllers. needs AC 18-0-18 voltage.positive, negative, and ground voltage. one input and one output. Every amplifier needs this type of board to control the sound.
DIY amplifier circuit using STK4141:
This is a DIY amplifier circuit using STK4141. We can get 25-0-25 watts using this diagram. We can use 15-0-15 voltage to a maximum of 24-0-24 voltage. The voltage depends on the IC quality. STK is the best sound quality amplifier. Sony Sound is making maximum use of the STK IC. It’s a stereo audio diagram. This diagram also includes a bass tone circuit with a pre-amplifier. The pre-amplifier uses the 4558D IC.
The diagram is
This circuit diagram uses one transistor C828. Here, 4 volumes. volume, bass, and high, and tone. This circuit is one of the best bass tone control circuits. It runs at 12 volts. Every amplifier needs this circuit to control the sound. This is a Stereo circuit diagram. we need a Stereo circuit when we are making an amplifier. Without a pre-amplifier amplifier can’t make the best quality of sound. Here in this circuit used OPA2134PA IC. it’s a dual-voltage preamplifier.
We have another post for you. like Amplifier circuit 200 watts
Transistor circuit for an amplifier
Build a Transformer or construct the transformer. Home Theater Circuit Diagram 5.1
